pdf Field Guide

pdf AutoLOK II Manual

pdf Operating Instructions for Draft Gear Removal Jack

pdf Operating Instructions for Double Groove plastic pellet gate

pdf Stuck Draft Gear Procedure Manual

pdf How to install the seal for Miner's pneumatic gate for plastics



DRAWINGS

DRAWINGS

BRAKE BEAMS
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
#18 #18 UNIT BRAKE BEAM for Composite Shoes BB818RH, BB818LH Download Drawing
#24 #24 UNIT BRAKE BEAM for Composite Shoes BB824RH, BB824LH Download Drawing
#18 #18 UNIT BRAKE BEAM for Composite Shoes, Non-Bushed BB1018RH, BB1018LH Download Drawing
#24 #24 UNIT BRAKE BEAM for Composite Shoes, Non-Bushed BB1024RH, BB1024LH Download Drawing
#18 & #24 Side Frame Wear Liner BUW116S Download Drawing
#18 & #24 Procedure to reverse Strut hand BE2001 Download Drawing
AutoLOK™ II
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
13" x 24" Weld On, Canadian, Center Runners MKE10450 Download Drawing
13" x 42" Bolt On (32-Hole) MKE10180 Download Drawing
13" x 42" Bolt On (32-Hole) with Support Bar MKE10180B Download Drawing
13" x 42" Bolt On (32-Hole) with Brush Seals MKE10180K Download Drawing
13" x 42" Bolt On (64-Hole) MKE10181 Download Drawing
13" x 42" Bolt On (64-Hole) with Support Bar MKE10181B Download Drawing
13" x 42" Bolt On (64-Hole) with Brush Seals MKE10181K Download Drawing
13" x 42" Bolt On (64-Hole) with Bag Holder MKE10183 Download Drawing
13" x 42" Bolt On (64-Hole) with Bag Holder and Brush Seals MKE10183K Download Drawing
13" x 42" Bolt On (64-Hole) Low Profile, Brush Seals MKE 10513 Download Drawing
13" x 42" Bolt On (32-Hole) For Lining MKE10507 Download Drawing
13" x 42" Bolt On (32-Hole) Deflector Hood MKE10625D Download Drawing
13" x 42" Bolt On (64-Hole) for Dense Materials MKE10705 Download Drawing
13" x 42" Bolt On (32-Hole) Galvanized MKE10845 Download Drawing
13" x 42" Bolt On (32-Hole) Bag Holder MKE10182 Download Drawing
15" x 48" Bolt On (64-Hole) MKE10615 Download Drawing
24" x 48" Bolt On (32-Hole) MKE10260 Download Drawing
24" x 48" Bolt On (64-Hole) MKE10315 Download Drawing
24" x 48" Bolt On (32-Hole) SS Door MKE10260A Download Drawing
24" x 48" Bolt On (32-Hole) SS Frame, SS Door MKE10260S Download Drawing
24" x 54" Bolt On (64-hole) MKE10571 Download Drawing
24" x 54" Bolt On (38-hole) Plastic Pellet Car Bolt Hole Pattern MKE10574 Download Drawing
25" x 54" Bolt On (38-Hole) Trinity PPG Bolt Pattern (tQ) MKE10630 Download Drawing
28" x 36" Weld-On, Canadian, Extended MKE10509 Download Drawing
30" x 30" Weld-On, Canadian MKE10162 Download Drawing
30" x 30" Weld On MKE10201 Download Drawing
30" x 30" Bolt On (66-Hole) MKE10200 Download Drawing
30" x 30" Bolt On (66-Hole) 1/2" Door, Wide Runner, SS Seal Frame MKE10608 Download Drawing
30" x 30" Bolt On (66-Hole) Lower Profile than MKE10200 MKE10611 Download Drawing
30" x 30" Weld On, Galvanized MKE10840 Download Drawing
30" x 30" Bolt On Thru Slope Sheets (32-Hole) MKE10645 Download Drawing
30" x 30" Weld On, Canadian, 1/2" Door, Wide Runners for Potash MKE10590 Download Drawing
42" x 42" Bolt On (66-Hole) Improved Bolt Access MKE10604 Download Drawing
42" x 52" Bolt On (60-hole) MKE10576 Download Drawing
BackLOK™ Gate
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
24" x 30" Weld On, No Seals MKE10514 Download Drawing
24" x 30" Bolt On (66-hole), No Seals MKE10588 Download Drawing
SelfLOK®
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
13" x 24" Weld On (Left Hand) MKE8671 Download Drawing
13" x 24" Weld On (Right Hand) MKE8672 Download Drawing
24" x 48" Weld On MKE10077 Download Drawing
SaniLOK®
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
27" x 30" SaniLOK Bolt On (66-Hole) with Plenum Hood MKE10410 Download Drawing
27" x 30" SaniLOK Bolt On (66-Hole) Sloped Sides MKE10679 Download Drawing
27" x 30" SaniLOK Bolt On (66-Hole) Deep Round Plenum MKE10713 Download Drawing
27" x 30" SaniLOK Bolt On (66-Hole) Sloped Sides, Plenum Hood MKE10773 Download Drawing
13" x 42" SaniLOK Bolt On (64-hole) All Stainless with Plenum Hood MKE50000 Download Drawing
Double Groove
SIZE DESCRIPTION NUMBER DOWNLOAD DRAWING
31 1/2" x 67 1/8" I-271-M Bolt-On (32-Hole) MKE10480-1 Download Drawing
29 13/16" x 75 13/16" I-289 Bolt-On (38-Hole) MKE10483-1 Download Drawing
28 5/16" x 74 5/16" I-289-C Bolt-On (38-Hole) MKE10637-1 Download Drawing
31 1/2" x 67 1/8" I-271-LP Pin Lock Bolt-On (32-Hole) MKE10647-1 Download Drawing
30 3/8" x 66" Bolt-On AQ Pattern (32-hole) MKE10658-1 Download Drawing
31 1/2" x 67 1/8" I-271-LP Bolt-On (32 hole) MKE10675-1 Download Drawing
